HORSEMEN'S SCHOOLING GATES • TRUE CENTER STARTING GATES • PARI-MUTUEL TRAINING GATES (Remington Park Race Track: Oklahoma City, OK) Specifications: The overhead and columns, that come down to the stall partitions, are made out of rectangular tubing 3" x 5" and 3/16" thick. Cross bracing also 3" x 5" is made entirely of square or rectangular tubing (all welded). The stall partitions are made out of 14 gauge galvanized or stainless steel. All front and back gates are padded with belting 3/8" thick. The stall partitions, where the horse's sides and legs might contact, are bonded with 1/8" neoprene. The inside of the stall is all lined and very smooth; will last indefinitely; takes the least care and maintenance and cushions any shock. The True Center Gate has manual and electrical locking systems. The stalls are 24" wide where the horse stands and 43" above (measured center to center). There is a 10' clearance from the ground and is transportable down the highway. True Center Gates, if kept painted, will last indefinitely. (Turf Paradise - Phoenix, Arizona) Return to the main menu
